Performance Characteristics
1. Feeding method: Single material is fed into the storage silo, with a small amount fed into the vibrating feeder for replenishment;
2. Suitable for: 3-5 specifications/day, single packaging of more than 200 packs;
3. Packaging Scope: Screws: Maximum size: M4-M10*40 and up; Nuts: M10 and up;
4. Weight range: 1-4KG. Bag size: Length adjustable from 100-300 mm, bag width 210 mm. One machine produces only one bag width.
5. Packaging speed: 200-300 packs/hour (500 packs/day for manual packaging);
6. Packaging accuracy: ±3-5/thousand (probabilistic); with the addition of sorting and weighing (re-inspection), accuracy can reach 99.9%.
7. The elevator's hopper has a load capacity of 500 kg, an independent touchscreen, independent control, low noise, and prevents material mixing.
Application Industry
● Buttons
● Screws
● Gaskets
● Terminals
● RJ45 Connectors
● Nails and other small hardware
Equipment Configuration
● Vertical packing system
● Feeding vibrating plate
● Weighing system
● Elevator
● Vibrating feeder
● Conveyor
● Printer (optional)
● Labeling system (optional)
● Sorting scale (optional)
Technical Parameters
| Measuring Range | 1KG-4KG |
| Packing Efficiency | 200-300 Bag/hour |
| Bag Length | 100-300mm |
| Bag Width | 190-210mm |
| Bag Making Forms | Back Seal |
| Thickness Of Film | 0.7-0.8mm |
| Packaging Materials | Composite membrane materials, aluminum foil, heat sealing film |
| Power Capacity | 2.4 KW |
| Power Voltage | 380V 50Hz 220V 50-60Hz |
| Air Pressure | 0.5-0.8Mpa |
| Machine Weight | 750kg |
| Machine Size | L1.1*W3.0*H1.6m |
| Case Material | Stainless Steel |
